| ONE-WAY
CLUTCHES--drawn cup roller clutches |
| Shaft
Diameter |
Clutch Designation
|
Weight
Approx |
Boundary Dimensions
|
Torque
|
Limiting Speed
|
Suitable Drawn Cup Bearings
|
|
Plastic Springs
|
Steel Springs
|
Fw |
D |
C |
Rotating Shaft Min-1
|
Rotating Outer Ring
Min-1 |
| mm |
g |
mm |
Nm |
rpm |
| HF series |
| 3 |
HF0306KF |
|
0.9 |
3 |
6.5 |
6 |
0.2 |
36000 |
7000 |
HK0306TN |
| 4 |
HF0406KF |
-- |
1 |
4 |
8 |
6 |
0.34 |
34000 |
8000 |
HK0408TN |
| HF0406KFR |
-- |
1 |
4 |
8 |
6 |
0.1 |
34000 |
8000 |
HK0408TN |
| 6 |
HF0608KF |
|
2.8 |
6 |
10 |
8 |
1.5 |
20000 |
11000 |
HK0608 |
| HF0612KF |
HF0612 |
3 |
6 |
10 |
12 |
1.76 |
23000 |
13000 |
HK0608 |
| HF0612KFR |
HF0612R |
3 |
6 |
10 |
12 |
0.5 |
23000 |
13000 |
HK0608 |
| |
HF061210 |
3.5 |
6 |
12 |
10 |
3 |
20000 |
13000 |
HK061208 |
| 8 |
HF0812KF |
HF0812 |
3.5 |
8 |
12 |
12 |
3.15 |
17000 |
12000 |
HK0808 |
| HF0812KFR |
HF0812R |
3.5 |
8 |
12 |
12 |
4 |
17000 |
12000 |
HK0808 |
| -- |
HF081210 |
3.2 |
8 |
12 |
10 |
3 |
16000 |
12000 |
HK0808 |
| -- |
HF081410 |
3.6 |
8 |
14 |
10 |
4.6 |
15000 |
11000 |
HK081410 |
| -- |
HF081610 |
4.1 |
8 |
16 |
10 |
5.5 |
15000 |
11000 |
HK081610 |
| -- |
HF081412 |
4 |
8 |
14 |
12 |
5 |
16000 |
12000 |
HK081410 |
| 10 |
HF1012KF |
HF1012 |
4 |
10 |
14 |
12 |
5.3 |
14000 |
11000 |
HK1010 |
| HF1012KFR |
HF1012R |
4 |
10 |
14 |
12 |
1.5 |
14000 |
11000 |
HK1010 |
| 12 |
-- |
HF1216 |
11 |
12 |
18 |
16 |
12.2 |
11000 |
8000 |
HK1212 |
| 14 |
-- |
HF1416 |
13 |
14 |
20 |
16 |
17.3 |
9500 |
8000 |
HK1412 |
| 16 |
-- |
HF1616 |
14 |
16 |
22 |
16 |
20.5 |
8500 |
7500 |
HK1612 |
| 18 |
-- |
HF1816 |
16 |
18 |
24 |
16 |
24.1 |
7500 |
7500 |
HK1812 |
| 20 |
-- |
HF2016 |
17 |
20 |
26 |
16 |
28.5 |
7000 |
6500 |
HK2010 |
| 25 |
-- |
HF2520 |
30 |
25 |
32 |
20 |
66 |
5500 |
5500 |
HK2512 |
| 30 |
-- |
HF3020 |
36 |
30 |
37 |
20 |
90 |
4500 |
4500 |
HK3012 |
| 35 |
-- |
HF3520 |
40 |
35 |
42 |
20 |
121 |
3900 |
3900 |
HK3512 |
| Shaft
Diameter |
Clutch Designation
|
Weight
Approx |
Boundary Dimensions
|
Torque
|
Limiting Speed
|
Basic Load Ratings
|
|
Plastic Springs
|
Steel Springs
|
Fw |
D |
C |
Rotating Shaft Min-1
|
Rotating Outer Ring Min-1 |
C |
Co |
| KN |
| mm |
g |
mm |
Nm |
rpm |
| HFL
series |
| 3 |
HFL0308 |
-- |
3 |
3 |
6.5 |
8 |
1 |
-- |
-- |
-- |
-- |
| 4 |
HFL0408 |
-- |
3.5 |
4 |
8 |
8 |
1.5 |
-- |
-- |
-- |
-- |
| 6 |
HFL0615KF |
HFK0615 |
4 |
6 |
10 |
15 |
1.76 |
23000 |
13000 |
-- |
-- |
| HFL0615KFR |
HFL0615R |
4 |
6 |
10 |
15 |
0.5 |
23000 |
13000 |
-- |
-- |
| -- |
HFL061012K |
5 |
6 |
10 |
12 |
-- |
21000 |
12000 |
-- |
-- |
| 8 |
-- |
HFL081212K |
6 |
8 |
12 |
12 |
-- |
20000 |
12000 |
-- |
-- |
| -- |
HFL081412K |
7 |
8 |
14 |
12 |
-- |
19000 |
12000 |
-- |
-- |
| HFL0822KF |
HFL0822 |
7 |
8 |
12 |
22 |
3.15 |
17000 |
12000 |
4.05 |
4.15 |
| HFL0822KFR |
HFL0822R |
7 |
8 |
12 |
22 |
1 |
17000 |
12000 |
-- |
-- |
| 10 |
HFL1022KF |
HFL1022 |
8 |
10 |
14 |
22 |
5.3 |
14000 |
11000 |
4.3 |
4.65 |
| HFL1022KFR |
HFL1022R |
8 |
10 |
14 |
22 |
1.5 |
14000 |
11000 |
-- |
-- |
| 12 |
-- |
HFL1226 |
18 |
12 |
18 |
26 |
12.2 |
11000 |
8000 |
6.3 |
6.5 |
| 14 |
-- |
HFL1426 |
20 |
14 |
20 |
26 |
17.3 |
9500 |
8000 |
7.1 |
7.7 |
| 16 |
-- |
HFL1626 |
22 |
16 |
22 |
26 |
20.5 |
8500 |
7500 |
7.7 |
9 |
| 18 |
-- |
HFL1826 |
25 |
18 |
24 |
26 |
24.1 |
7500 |
7500 |
8.3 |
10.3 |
| 20 |
-- |
HFL2026 |
27 |
20 |
26 |
26 |
28.5 |
7000 |
6500 |
8.9 |
11.5 |
| 25 |
-- |
HFL2530 |
44 |
25 |
32 |
30 |
66 |
5500 |
5500 |
10.9 |
14.1 |
| 30 |
-- |
HFL3030 |
51 |
30 |
37 |
30 |
90 |
4500 |
4500 |
12.6 |
17.6 |
| 35 |
-- |
HFL3530 |
58 |
35 |
42 |
30 |
121 |
3900 |
3900 |
13 |
19.3 |
